Sparkle Intel Arc A770 ROC OC Edition 16GB GDDR6 Graphics Card

Specification

Brand

Sparkle

Chipset

Intel

Series

A 700

Chipset Model

Intel Arc A770

Model

Sparkle Intel Arc A770 ROC OC Edition 16GB

Boost Engine Clock Speed

2300MHz

Memory Clock

17.5Gbps

Capacity (GB/TB)

16GB

Memory Type

GDDR6

Interface(s)

PCI Express 4.0 x16

Graphics Resolution Max.

7680 x 4320

DirectX Support

12 Ultimate

OpenGL Support

4.6

Approx. Power Consumption

225W

Recommended PSU

650W

Multi Display Capability

Quad Display

Cooler Type

Fan

Lighting

LED

Body Color

Black

Warranty Details

3 Year (No Warranty for Mining)

Description

Features of Sparkle Intel Arc A770 ROC OC Edition 16GB Graphics Card

Brand – Sparkle, Chipset Vendor – Intel, Series – A 700, Chipset Model – Intel Arc A770, Model – Sparkle Intel Arc A770 ROC OC Edition 16GB, Engine Clock – 2300MHz (Boost), Boost Engine Clock Speed – 2300MHz, Memory Clock – 17.5Gbps, Memory Size – 16GB, Memory Bus – 256-bit, Memory Bandwidth – 560 GB/s, Memory Type – GDDR6, Interface – PCI Express 4.0 x16, Digital Max Resolution – 7680 x 4320, DirectX – 12 Ultimate, OpenGL – 4.6, VGA Port – No, DVI Port – No, HDMI Port – 1, Displayport – 3, Approx. Power Consumption – 225W, Recommended PSU – 650W, Multi Display Capability – Quad Display, Card Dimension – 261 x 118 x 48.4mm, Cooler Type – Fan, Cooling Fan – Dual, Lighting – LED, Supported OS – Windows 11, 10. Ubuntu 22.04, Body Color – Black, Others – Xe-Core: 32. Ray Tracing Units: 32. Intel XMX Engines: 512. Xe Vector Engines: 512. HDMI 2.0b (Max): 4096 x 2160 60Hz. DisplayPort 2.0* (Max): 7680 x 4320 60Hz. REQUIREMENTS: Two available 8-pin or 6+2pin PCIe Connector, PCI Express 3.0, 4.0 or 5.0 compliant motherboard with one graphics slot. Weight: 880 gm. Width: 2.5 Slots., Specialty – The SPARKLE Intel Arc A770 ROC OC Edition is the brand-new BEST choice of the series, comes with Intel Arc A770 and 16GB GDDR6. This card is designed for ultimate gaming experience and maximum productivity. ROC series equipped dual 100mm double-ball bearing fans with 2.5-slot heatsink design, reduce the length of card effectively and ready to fit into the compact system. Furthermore, 100mm DBB fans have brought the higher efficiency of cooling, leading to an ultra silence experience without compromising performance. 2x 100mm Double-Ball Bearing Fans. Metal Backplate, Pre-Installed. Ray Tracing. Variable Rate Shading (VSR). DirectX 12 Ultimate. Vulkan 1.3. OpenGL 4.6 OpenCL 3.0. Adaptive Sync. AV1 Encode / Decode. VP9 Bitstream & Decoding. Intel Deep Link Hyper Compute. Intel Deep Link Hyper Encode. Intel Deep Link Stream Assist., Part No – SA770R-16GOC, Warranty – 3 Year (No Warranty For Mining), Country of Origin – Taiwan.
