Specification
| Brand | GIGABYTE | |
| Type | GDDR6 | |
| Size | 16 GB | |
| Resolution | 7680×4320 | |
| Core Clock | Boost Clock: up to 2285 MHz (Reference card: 2250 MHz)
Game Clock: up to 2050 MHz (Reference card: 2015 MHz) |
|
| Memory Clock | 16000 MHz | |
| BUS Type | 256-bit | |
| Memory Interface | 16GB GDDR6 256-bit | |
| Stream Processors | 5120 | |
| Interface | ||
| DisplayPort | 2 x DisplayPort 1.4a | |
| HDMI | 2 x HDMI 2.1 | |
| Power Specifications | ||
| Connectors | 3 x 8 pin | |
| Recommended PSU | 850W | |
| Display Option | ||
| Multi Display | 4 | |
| Application Programming Interfaces | ||
| DirectX | 12 Ultimate | |
| OpenGL | 4.6 | |
| Physical Specifications | ||
| Dimensions | L=286 W=118 H=58 mm | |
| Others | PCB Form: ATX | |
| Warranty | ||
| Manufacturing Warranty | 2 years | |
Description
GIGABYTE Radeon RX 6900 XT GAMING OC 16GB GDDR6 Graphics Card
The GIGABYTE Radeon RX 6900 XT GAMING OC 16GB GDDR6 Graphics Card has a boost clock of up to 2285 MHz and a game clock of up to 2050 MHz. It features WINDFORCE 3X cooling system features 3x 80mm unique blade fans, alternate spinning, 6 composite copper heat pipes, large copper plate direct touch GPU and 3D active fan, which together provide high-efficiency heat dissipation. Alternate Spinning can reduce the turbulence of adjacent fans and increase air pressure. The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game. The airflow is split by the triangular fan edge and guided smoothly through the 3D stripe curve on the fan surface. Graphene nano lubricant can extend the life of the fan by 2.1 times, close to the life of double ball bearing, and is quieter. It features a large copper plate and heat pipe. With direct contact to the GPU and VRAM, the large copper plate combines the composite heat pipes to efficiently transfer heat generated from the interior cores to the heat sink. It features RGB Fusion 2.0 with 16.7M customizable color options and numerous lighting effects, you can choose lighting effects or synchronize with other AORUS devices. It comes with a protective metal backplate. The metal back plate not only provides an aesthetical shape but also enhances the structure of the graphics card to provide complete protection. It supports dual bios. The silent mode will provide a quieter experience. The mode switch requires a reboot to take effect. The default is OC mode. The GIGABYTE Radeon RX 6900 XT GAMING OC comes with 2 years of warranty.
