Specification
| Basic Information | ||
| Supported CPU | LGA1700 socket: Support for the 14th Gen, 13th and 12th Generation Intel Core, Pentium Gold and Celeron Processors
L3 cache varies with CPU |
|
| Chipset | Intel Z790 Express Chipset | |
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm | |
| BIOS | 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Audio | Realtek Audio CODEC
High-Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out |
|
| Expansion Slots | ||
| PCI | CPU:
1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2) Support for AMD CrossFire technology (PCIEX16 and PCIEX4) |
|
| Memory | ||
| Supported Memory | Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules
Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules |
|
| Slots | 4 x DIMM sockets | |
| Type | DDR5 | |
| Maximum Memory | up to 192 GB (48 GB single DIMM capacity) | |
| Graphics | ||
| Graphics | Integrated Graphics Processor-Intel® HD Graphics support:
1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz * Support for HDMI 2.0 version and HDCP 2.3. 1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 * Support for DisplayPort 1.2 version and HDCP 2.3 |
|
| Connector & Ports | ||
| Display Port (s) | 1 x DisplayPort | |
| HDMI | 1 x HDMI | |
| USB (s) | Chipset:
1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2×2 support 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header) Chipset+2 USB 2.0 Hubs: 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) |
|
| LAN Port (s) | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) | |
| Wireless Communication module | Intel® Wi-Fi 6E AX211 (PCB rev. 1.0)
WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate Realtek Wi-Fi 6E RTL8852CE (PCB rev. 1.1) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate |
|
| Supported Storage | CPU:
1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset: 2 x M.2 connectors (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB, M2Q_SB) 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 SSD support) (M2M_SB) 6 x SATA 6Gb/s connectors |
|
| RAID | RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
|
| Audio | 2 x audio jacks | |
| Internal I/O Ports | 1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 4 x M.2 Socket 3 connectors 6 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt add-in card connectors 1 x reset button 1 x Q-Flash Plus button 1 x Clear CMOS button 1 x reset jumper 1 x Clear CMOS jumper |
|
| TPM (Trusted Platform Module ) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | |
| Others | ||
| Special Features | Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup |
|
| Bundled Software | Norton Internet Security (OEM version)
LAN bandwidth management software |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 years | |
Description
GIGABYTE ATX Motherboard Z790 AORUS ELITE AX ICE The GIGABYTE Z790 AORUS ELITE AX ICE ATX Motherboard is a high-performance motherboard that is compatible with Intel’s LGA 1700 socket. It supports Intel Core CPUs from the 14th, 13th, and 12th generations, making it a flexible and future-proof alternative for PC enthusiasts and gamers. This motherboard supports Intel’s 14th, 13th, and 12th Generation Series Processors, allowing you to take advantage of modern CPU technology. The motherboard provides outstanding performance with a double 16+1+2 phase digital VRM technology, delivering consistent power delivery for your CPU and whole system. You may enjoy quicker and more responsive system memory with dual-channel DDR5 memory support, 4*SMD DIMMs, and XMP 3.0 Memory Module support. Four PCIe 4.0 x4 M.2 ports deliver lightning-fast storage, ensuring your system can easily handle demanding apps and games. The M.2 Thermal Guard III and sophisticated thermal design features aid in the maintenance of VRM power stability and the optimization of M.2 SSD performance, even under severe workloads. The M.2 connections are fast-release and screwless, making it simple to install and change out M.2 drives without the worry of screws and intricate installation. You may experience ultra-fast network access for online gaming, streaming, and productivity with 2.5GbE LAN and Wi-Fi 6E (802.11ax). The motherboard has DP and HDMI connectors for numerous displays, as well as front and rear USB-C ports with remarkable data transfer rates of 10Gb/s and 20Gb/s, respectively. Smart Fan 6’s various temperature sensors and hybrid fan headers provide precise management of system cooling. When the system is not under significant demand, Fan Stop technology aids in maintaining silent operation. Thanks to the Q-Flash Plus function, updating the BIOS has never been easier. You may upgrade the BIOS without installing the CPU, RAM, or graphics card, which saves time and effort throughout the update process.
Buy GIGABYTE ATX Motherboard Z790 AORUS ELITE AX ICEÂ
In Bangladesh, you can get the original GIGABYTE Motherboard ATX Z790 AORUS ELITE AX ICE . We have a large collection of the latest GIGABYTE Motherboard to purchase for your Desktop PC. Order Online or Visit your Nearest Shop to get yours at lowest price. The GIGABYTE Z790 AORUS ELITE AX ICE ATX Motherboard comes with 3 years warranty.
What is the price of GIGABYTE ATXÂ Motherboard Z790 AORUS ELITE AX ICE in Bangladesh?
The latest price of GIGABYTE Z790 AORUS ELITE AX ICE ATX Motherboard in Bangladesh is 41,000৳. You can buy the GIGABYTE Z790 AORUS ELITE AX ICE ATX Motherboard at best price from our website or visit any of our showrooms.
