Specification
| Brand | Deepcool | |
| Efficiency (Approx.) | ≥90% Under Typical Load(50% Loading) | |
| Certification | 80 PLUS Gold Certified | |
| Fan Size | 120mm | |
| Others | MTBF: 100,000 Hours | |
| Input | ||
| Frequency Range | 50/60 Hz | |
| Output | ||
| Modular Type | Full Modular | |
| Total Power | 650 Watt | |
| Connector | ||
| Main Power | 24(20+4)Pin × 1 | |
| CPU | CPU(4+4)Pin x 1
12V-2×6(16Pin) x 1 |
|
| PCI-E | PCI-E(6+2)Pin x 1 | |
| SATA | SATA x 4 + 4Pin Peripheral x 1 | |
| Warranty Information | ||
| Manufacturing Warranty | 10-year warranty | |
Description
DeepCool PN650M 650W 80 Plus Gold Fully Modular Power Supply
The DeepCool PN650M 650W 80 Plus Gold Fully Modular Power Supply is a state-of-the-art power supply unit designed to meet the latest Intel ATX 3.1 and PCIe 5.1 standards. This PSU is engineered for high-performance computing, offering robust power delivery with a dedicated 12V-2×6 connector and five EPS/PCIe ports, ensuring compatibility with modern, high-power components such as GPUs and CPUs. Its future-proof design allows it to handle power spikes efficiently, delivering double the total system power for brief periods of up to 0.1 milliseconds, thus guaranteeing stable and consistent power for both current and next-generation PCs. Certified with the 80 Plus Gold rating, the PN650M operates with high energy efficiency, achieving up to 90% efficiency under typical loads. This certification, along with a Gold rating from Cybernetics, highlights its performance and reliability. The power supply is constructed with premium components, including a main Japanese electrolytic capacitor, active Power Factor Correction (PFC), full-bridge Series Resonant Converter (SRC) LLC, and a DC-to-DC topology. These high-quality parts ensure the PSU maintains a hold-up time of at least 16 milliseconds, even under heavy load conditions, ensuring stable power delivery during demanding tasks. Equipped with a high-grade 12V-2×6 cable made from a 16AWG copper core, the PN650M is capable of delivering up to 600W of power to support the latest GPUs. It also comes with pre-sleeved cables, adding a premium aesthetic and professional finish to your build. The PSU features a dynamic 120mm Fluid Dynamic Bearing (FDB) fan, which adjusts its speed based on the cooling needs of the unit, providing efficient temperature management and quiet operation. Additionally, the PN650M is built to withstand harsh conditions, capable of operating effectively at altitudes of up to 5000 meters, showcasing its robustness and durability. The DeepCool PN650M is an ideal choice for users seeking a reliable, efficient, and future-proof power supply solution for their high-performance computing needs, whether for gaming or professional workstations. It comes with a comprehensive warranty and is available through various online and physical retailers. DeepCool also provides extensive customer support and technical assistance, ensuring that users have access to help whenever needed. This PSU is an excellent option for those looking to upgrade or build a powerful, efficient, and reliable computer system that meets the demands of modern technology.
