Specification
| Brand | Dahua | |
| Casing | Metal front cover + plastic main body + metal bracket | |
| Dimensions | 198.4mm×80.2mm×76.2mm (7.81″×3.16″×3.00″) | |
| Weight | 0.3Kg | |
| Pan/Tilt/Rotation | Pan: 0°–360°
Tilt: 0°–180° Rotation: 0°–360° |
|
| Operating Conditions | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) | |
| Storage Conditions | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) | |
| Power Supply | 12V ±30% DC | |
| Power Consumption | Max 5W (12V DC, white light on) | |
| Camera | ||
| Image Sensor | 1/2.8 inch 2.16 Mega Pixels CMOS | |
| Effective Pixels | 1920 (H)×1080 (V), 2MP | |
| Electronic Shutter Speed | PAL:1/25s–1/100000s
NTSC:1/30s–1/100000s |
|
| Minimum Illumination | 0.005Lux/F1.6, 30IRE, 0 Lux white Light on | |
| IR Distance | Distance up to 40m (131.23ft) | |
| IR On/Off Control | Auto; Manual | |
| IR LEDs | 2 | |
| Lens | ||
| Lens Type | Fixed-focal
Fixed iris |
|
| Mount Type | M12 | |
| Focal Length | 2.8m/3.6mm | |
| Max Aperture | F1.6 | |
| Angle of View | 2.8mm:
126.2°×106.0°×56.5° (diagonal horizontal vertical) 3.6mm: 103.6°x86.9°x46.3° (diagonal horizontal vertical) |
|
| Close Focus Distance | 2.8mm: 0.6m (1.97ft)
3.6mm: 1.2m (3.94ft) |
|
| Video | ||
| Resolution | 1080P (1920×1080); 720P (1280×720); 960H (704×
576/704×480) |
|
| Frame Rate | CVI:
PAL: 1080@25fps, 720@25fps, 720@50fps; NTSC: 1080@30fps, 720@30fps, 720@60fps AHD: PAL: 1080@25fps,720@25fps; NTSC: 1080@30fps,720@30fps TVI: PAL: 1080@25fps,720@25fps,720@50fps; NTSC: 1080@30fps,720@30fps,720@60fps CVBS: PAL: 960×576H; NTSC: 960×480H |
|
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one
BNC port |
|
| BLC Mode | BLC/HLC/WDR | |
| Gain Control | Auto; Manual | |
| Noise Reduction | 2D NR | |
| Interface | ||
| Audio Interface | Built-in mic(-A) | |
| Warranty | 1 Year | |
Description
Dahua HAC-HFW1239TLMP-A-LED 2MP HDCVI Full Color IR Bullet Camera with Audio
Experience 1080P full HD color video and the simplicity of reusing existing coaxial infrastructure with HDCVI. The full-color starlight HDCVI camera presents a high quality color image with rich details even in total darkness conditions. It offers various fixed lens models with a multi-language OSD and HD/SD switchable output. It adopts two powerful warm white LED illuminators, covering an effective range up to 40m(131.23ft). The LEDs switch on automatically in darkness to capture detail-packed full-color images 24/7, ensuring authentic identification of objects. It is an ideal choice for applications such as schools, retail centers and parking lots. The camera adopts F1.6 large aperture lens and 1/2.8″ high performance sensor. With a higher amount of absorbed light and advanced image processing algorithm, the camera presents an impressive low light performance with an exceptional balance between noise reduction and the blur of moving objects. With two warm supplemental LED lights, the camera is able to provide a colorful and vivid image even in total darkness. It also provides visibility By default, the camera is set to smart light mode, in which the camera can automatically adjust the exposure time and light sensitivity simultaneously to avoid over exposure of the objects in the image center. Also, the sensitivity and intensity of the LED lights can be remotely controlled by OSD menu. Audio information is used as supplementary evidence in video surveillance applications. The HDCVI camera supports audio signal transmission over coaxial cable. In addition, it adopts unique audio processing and transmission technology that best restores source audio and eliminates noise, guaranteeing the quality and effectiveness of collected audio information. HDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio, data and power. Dual-way data transmission allows the HDCVI camera to interact with the HCVR, such as sending control signals or triggering alarms. Moreover, HDCVI technology supports PoC for construction flexibility. HDCVI technology guarantees long-distance and real-time transmission without any loss. It supports up to 800m for 1080P Full HD video via coaxial cable, and up to 300m via UTP cable. HDCVI technology inherits the born feature of simplicity from traditional analog surveillance systems, making itself a best choice for investment protection. HDCVI systems can seamlessly upgrade the traditional analog system without replacing existing coaxial cabling. The plug and play approach enables full HD video surveillance without the hassle of configuring a network. The camera supports multiple video formats including HDCVI, CVBS and other two common HD analog formats in the market. The four formats can be switched over through OSD menu or by PFM820(UTC controller).This feature makes the camera compatible with most end users existing HD/SD DVRs. The camera’s outstanding reliability is unsurpassed due to its rugged design. The camera is protected against water and dust with IP67 ranking, making it suitable for indoor or outdoor environments.
