ASRock B760 Pro RS ATX Motherboard

Name: ASRock B760 Pro RS ATX Motherboard
SKU: 44857
Availability: InStock

Original price was: 25,080.00 ৳ .Current price is: 21,750.00 ৳ .

Key Features
Model: B760 Pro RS
Brand: ASRock
Features: Dragon 2.5G LAN
Supported RAM: 4x DDR5, Max 192GB 7200+(OC)
Graphics Output: 1x HDMI, 1x DisplayPort, 1x eDP
Supported CPU: 14th, 13th & 12th Gen Intel Core Processors (LGA1700)

Add to compare

Add to wishlist

15 People watching this product now!

Specification and Description

Specification

*Brand*	*ASRock*
*Supported CPU*	*Supports 14th, 13th Gen & 12th Gen and next gen Intel Core Processors (LGA1700)* *Supports Intel Hybrid Technology* *Supports Intel Turbo Boost Max 3.0 Technology* *Supports Intel Thermal Velocity Boost (TVB)* *Supports Intel Adaptive Boost Technology (ABT)*
*Chipset*	*Intel B760*
*BIOS*	*128Mb AMI UEFI Legal BIOS with GUI support*
*Form Factor*	*ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm*
*Audio*	*7.1 CH HD Audio (Realtek ALC897 Audio Codec)* *Nahimic Audio*
*Expansion Slots*
*PCI*	*CPU:* – 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode* *Chipset:* – 1 x PCIe 4.0 x16 Slot (PCIE3), supports x4 mode* – 1 x PCIe 3.0 x16 Slot (PCIE4), supports x1 mode* – 1 x PCIe 3.0 x1 Slot (PCIE2)* *– 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel CNVio/CNVio2 (Integrated WiFi/BT)* *– Supports AMD CrossFire*
*Memory*
*Type*	*DDR5*
*Slots*	4
*Supported Memory*	*Dual Channel DDR4 Memory Technology* *4 x DDR5 DIMM Slots* Supports DDR5 non-ECC, un-buffered memory up to 7200+(OC)* *Supports Intel Extreme Memory Profile (XMP) 2.0* *1DPC 1R Up to 7200+ MHz (OC), 4800 MHz Natively.* *1DPC 2R Up to 6000+ MHz (OC), 4400 MHz Natively.* *2DPC 1R Up to 5600+ MHz (OC), 4000 MHz Natively.* *2DPC 2R Up to 4800+ MHz (OC), 3600 MHz Natively.*
*Maximum Memory*	*192GB*
*Graphics*
*Graphics*	*Intel Xe Graphics Architecture (Gen 12)* *1 x eDP 1.4, supports max. resolution up to Full HD 60Hz* *1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz* *1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz*
*Connector & Ports*
*HDMI*	*1x HDMI*
*Display Port (s)*	*1 x eDP* *1x DisplayPort*
*USB (s)*	*2 x USB 3.2 Gen2 Type-C (1 Rear, 1 Front)* *1 x USB 3.2 Gen2 Type-A (Rear)* *6 x USB 3.2 Gen1 (4 Rear, 2 Front)* *4 x USB 2.0 (2 Rear, 2 Front)* * All USB ports support ESD Protection
*LAN Port (s)*	*2.5 Gigabit LAN 10/100/1000/2500 Mb/s* *Dragon RTL8125BG* *Supports Dragon 2.5G LAN Software* *– Smart Auto Adjust Bandwidth Control* *– Visual User Friendly UI* *– Visual Network Usage Statistics* *– Optimized Default Setting for Game, Browser, and Streaming Modes* *– User Customized Priority Control*
*Supported Storage*	*CPU:* – 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* *Chipset:* – 1 x M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x2 (32 Gb/s) mode* – 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* *– 4 x SATA3 6.0 Gb/s Connectors*
*RAID*	*Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices*
*Audio*	*HD Audio Jacks: Line in / Front Speaker / Microphone*
*Internal I/O Ports*	*1 x eDP Signal Connector* *1 x Power LED and Speaker Header* *2 x RGB LED Headers* *2 x Addressable LED Headers* *1 x CPU Fan Connector (4-pin)* *1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)* *5 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)* *1 x 24 pin ATX Power Connector* *2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)* *1 x Front Panel Audio Connector* *1 x Thunderbolt AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card)* *1 x USB 2.0 Header (Supports 2 USB 2.0 ports)* *1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)* *1 x Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s)*
*TPM (Trusted Platform Module )*	*1 x SPI TPM Header*
*Others*
*Special Features*	*Superb Productivity* *– PCIe Gen5 (Graphics)* *– Dual Channel DDR5* *Rock-Solid Durability* *– 10+1+1 Power Phase, 50A Dr. MOS for VCore+GT* *– Pre-Installed I/O Shield* *Ultrafast Connectivity* *– 2.5G LAN* *EZ Update* *– ASRock Auto Driver Installer* *EZ Troubleshooter* *– ASRock Post Status Checker*
*Bundled Software*	*Software* *– ASRock Motherboard Utility (A-Tuning)* *– ASRock Dragon 2.5G LAN Software* – ASRock Polychrome SYNC* *UEFI* *– ASRock EZ Mode* *– ASRock Full HD UEFI* *– ASRock My Favorites in UEFI* *– ASRock Auto Driver Installer* *– ASRock Instant Flash* *– ASRock Easy RAID Installer*
*Manufacturing Warranty*	*3 years*

Description

ASRock B760 Pro RS ATX Motherboard

The ASRock B760 Pro RS is a ATX motherboard designed to support 14th, 13th Gen, and 12th Gen Intel Core processors with LGA1700 socket. With a 7+1+1 Power Phase and Dr. MOS for VCore+GT, it ensures efficient and stable power delivery to the CPU. The 14th Gen Motherboard supports DDR5 memory at speeds up to 7200MHz (OC), allowing for smooth multitasking and enhanced performance. It is equipped with multiple PCIe slots, including 2 PCIe 4.0 x16, 1 PCIe 3.0 x16, and 1 PCIe 3.0 x1, the ASRock B760 Pro RS offers great expansion possibilities for graphics cards and other peripherals. It also features M.2 slots for high-speed storage solutions. The ASRock B760 Pro RS Motherboard provides a variety of connectivity options, including HDMI and DisplayPort for graphics output, USB 3.2 Gen2 Type-C and USB 3.2 Gen1 Type-C ports (both rear and front), as well as USB 3.2 Gen1 Type-A and USB 2.0 ports for connecting various devices. It comes with Realtek ALC897 7.1 CH HD Audio Codec with Nahimic Audio for high-quality audio output and Dragon 2.5G LAN for fast and reliable network connectivity.
